Battery Charger
The OpenEPT Battery Charger is a dedicated hardware platform for controlled charging of batteries used within the OpenEPT ecosystem. It is designed to operate together with the Energy Profiler Probe, enabling battery charging, characterization, controlled discharge, and energy profiling within the same experimental platform.
Technical specifications
| Charging | |
|---|---|
| Programmable charging current | Up to 1 A |
| Programmable terminal voltage | 3.65 – 4.5 V |
| Terminal current | 5%, 10%, or 20% of the programmed charging current |
| Integration | |
| OpenEPT integration | Dedicated interface for integration with the Energy Profiler Probe |
| Communication | I2C and UART |
Need a custom configuration?
If you want custom options that are compatible with the current design, ask our team and we can create a modification tailored to your needs.
Device description
Overview
OpenEPT Battery Charger is a programmable battery charging platform designed for battery testing, characterization, and development. The board can be used as a standalone charger or integrated with the OpenEPT Energy Profiler Probe (EPP) to create a complete platform for automated battery experiments.
What it enables
- standalone programmable battery charging
- configurable and repeatable charging experiments
- monitoring and control of the battery charging process
- automated charge and discharge cycles when combined with the EPP
- battery characterization and parameter extraction
- development and evaluation of battery-powered embedded systems
Standalone operation
The Charger can operate independently as a battery charging platform, allowing charging parameters to be configured and the charging process to be monitored without requiring the Energy Profiler Probe.
Integration with OpenEPT EPP
The Charger includes a dedicated interface for integration with the OpenEPT Energy Profiler Probe. When used together, the two boards provide control over both charging and discharging of the connected battery, while the EPP simultaneously measures battery voltage and current.
This integration enables automated battery characterization workflows, including repeated charge/discharge cycles, acquisition of battery voltage and current profiles, capacity analysis, and extraction of parameters required for battery modeling and State-of-Charge (SoC) estimation.
Development workflow
The Charger can be used for standalone battery charging during development or as part of a complete OpenEPT battery characterization setup. Combined with the EPP and OpenEPT software tools, it provides a platform for automating experiments that would otherwise require manual control of separate charging, loading, and measurement equipment.
